MERCMASTER III LOW PROFILE Z2

Appleton Electric
MERCMASTER III LOW PROFILE Z2

Part Number: MLBG64FBUZ2
UPC: 00781381096201
Call for Price
  • Manufacturer may be Out Of Stock.
Changes Selections Above Number Of Lamps...
Changes Selections Above Specific Products...
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
Mercmaster III ML Series Ballast Body, Lamp Type: (2) 32 WTT 4800 LM 82 CRI 10000 HR PL-T Fluorescent (Included), Lamp Wattage: 32 WTT, Voltage Rating: 120 - 277 V, 125 VDC, Number Of Lamps: 2, Material: Die-Cast Copperfree (4/10 Of 1 PCT Maximum) Aluminum Mounting Hood And Guard, Stainless Steel Hardware And Latch Assembly, Fixture Wattage: 69 WTT, Amperage Rating: 0.26 AMP Starting, 0.26 AMP Operating At 277 V, Housing Finish: Epoxy Powder Coat, Housing Material: Die-Cast Copperfree (4/10 Of 1 PCT Maximum) Aluminum, Ambient Temperature Range: 55 DEG C, Temperature Range: 75 DEG C Supply Wire, Ballast Type: Electronic, Ballast Quantity: 1, Frequency Rating: 50/60 HZ, Standard: Class I, Zone 2, AEx nA nR IIC, For Glass Globe Or Polymeric Refractor
Specifications
Details
Product Height:
7.80"
Product Width:
12.40"
Product Length:
12.40"
Electrical Category:
Lamps, Bulbs, and Lighting Fixtures
Electrical Subcategory:
Lighting Fixtures
Amperage Rating:
0.26 AMP Starting, 0.26 AMP Operating At 277 V
Application:
For Glass Globe Or Polymeric Refractor
Ballast Type:
Electronic
Brand Name:
Appleton
Brochure:
Manufacturer Brochure
Country Of Origin:
MX
Lamp Type:
(2) 32 WTT 4800 LM 82 CRI 10000 HR PL-T Fluorescent (Included)
Material:
Die-Cast Copperfree (4/10 Of 1 PCT Maximum) Aluminum Mounting Hood And Guard, Stainless Steel Hardware And Latch Assembly
Number Of Lamps:
2
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
RoHS Compliance:
Contact Manufacturer
Spec Sheet:
Spec Link
Special Features:
Compact fluorescent lamps provide superior energy efficiency and long lamp life thereby reducing relamping costs; Epoxy powder coat finish electrostatically applied for complete uniform corrosion protection; compact fluorescent light sources possess superi
Standard:
Class I, Zone 2, AEx nA nR IIC
Sub Brand:
Mercmaster III
Type:
ML Series Ballast Body
UNSPSC:
39111501
Voltage Rating:
120 - 277 V, 125 VDC
Warranty Link:
Warranty Information
Weight:
6.050 L
